Depending on the customer`s request, we can offer air slide fabric made of different raw materials, in various grades of airpermeability and thickness, depending on the application.Click here to download the product description
Depending on the customer`s request, we can offer air slide fabric made of different raw materials, in various grades of airpermeability and thickness, depending on the application.Click here to download the product description
We use large fiber company's fiber plant production of 1.2 denier, 2 denier, 2.5 denier high-quality polyester denier and imported equipment for the production of polyester filter felt. The machine can be more than five different materials, different specifications of the fiber evenly quantitative mixing, and then mixed with multiple sets of cotton and carding unit will help the fiber between the layers of different fiber composite layer, gradient transformation.
In addition to the product with the ordinary blanket-specific high-porosity, permeability, and dust-efficient, long life and other advantages, Its moderate temperature rating, instantly up to 150 ° C, acid and alkali-resistant features and has a very good wear resistance. Therefore, polyester filter bag is the most common materials in the filter bag family. Weight from 350g / m2 ~ 600g / m2, thickness from 1mm ~ 4mm, width 2.5 meters below our factory can produce, and can be cut to a variety of width.
Surface after hot rolling, singeing or coating and other post-processing, so that the surface smooth and difficult to be blocked by dust, the filter porosity, air permeability is better, uses a wide range of anti-chemical stability, not only can Filtration at room temperature gas, and can filter corrosive gases containing acid and alkali, and filter water, oil filter, is the normal temperature conditions, liquid-solid separation and other areas of the ideal filter material.
|
Fibre Composition |
Polyester staple fiber |
|
|
Scrim Composition |
Polyester filament |
|
|
Weight |
500 |
g/m2 |
|
Thickness |
1.9 |
mm |
|
Mean Air Permeability |
9-12 |
m3/m2/[email protected] |
|
Breaking Strength-CD ( warp ) |
≥1000 |
N/5x20cm |
|
Breaking Strength-MD (weft) |
≥1300 |
N/5x20cm |
|
Breaking Elongation-CD |
<30 |
% |
|
Breaking EIongation-MD |
<50 |
% |
|
Dry Shrinkage-CD |
< 1 |
% |
|
Dry Shrinkage-MD |
< 1 |
% |
|
Recommended Continous Operating Temperature |
130 |
°C |
|
Recommended Short-term Operating Temperature |
150 |
°C |
|
Finishing |
Singeing, calendering, heat setting treatment |
|
Depending on the customer`s request, we can offer air slide fabric made of different raw materials, in various grades of airpermeability and thickness, depending on the application.Click here to download the product description
Specifications: B250mm, B270mm, B480mm, B580mm; other air slide fabric specifications between 10mm to 1600mm can be produced at any time according to user needs; more than 1600mm of special specifications to be agreed in advance.
Material: Polyester Staple Fiber.
Lenght (m)：20-100. Width (m): 0.1-1.6 Thickness: 5-6mm.
Breathability:2m3/m2 min:800pa-1200pa.<3m3/m2 min:<2000pa
Breaking Strength (N/mm):Warp Direction≧ 470N/mm ,Weft Direction≧ 350N/mm .
Operating Temperature (℃): Continuous Operation 220 ,Instant Operation 250 .
Air slide fabric is also named Air slide canvas, Air slide belt fabric, Complete set aero cloth，air slide fabrics, air slide fabric, Solid Woven Air Slide Material, Air permeable fabric, Pneumatic conveyor belt,Aeration pad, Fabrics for air slides.
The airslide fabrics (air slide fabric,airslide fabric) is one of our products.More than 100 world-renowned companies such as Lafarge, TCC and other selected our products.
China Sunrise Machinery (CSM)is a professional cement equipment manufacturing enterprise. We were named one of the "China Machinery Industry's Most Famous Brands”. All the cement machinery products have passed three standard embraced in one system, consisted of ISO9001, ISO14001, and OHSAS18001. Five types of the products have get European CE certification, meanwhile it owns about 30 patented products &high-tech products.
